Semicon 2.0: Where Will ₹1.27 Lakh Crore Really Create Wealth?

India’s semiconductor policy has entered the phase in which ambition becomes expensive.

On July 15, the Union Cabinet approved Semicon 2.0 with an outlay of ₹1.275 lakh crore, extending a national effort that began in 2021 as a response to supply-chain fragility and has since become part of a much larger contest over technology, industrial capacity and strategic autonomy. Under the first phase, 12 manufacturing projects representing more than ₹1.64 lakh crore of cumulative investment were approved. Kaynes and CG Semi have commenced production-related operations, while India’s first large silicon fab at Dholera is expected to begin production in 2028. For markets, however, the most tempting conclusion is also the most dangerous: a large government commitment does not automatically translate into large shareholder returns.

Semiconductors are not one industry. They are a chain of highly specialised businesses with radically different capital intensity, competitive moats, technology risks and bargaining power. A wafer fab, a packaging company, a supplier of ultra-pure gases, an electronics manufacturer and a chip-design house may all sit under the same policy umbrella, but they do not create value in the same way. Nor does strategic importance guarantee attractive returns on capital.

That distinction is the real investment story behind Semicon 2.0. The policy’s most consequential change is not simply more money for more fabs. It is the decision to widen the field to chip design, machines, materials, chemicals, gases, advanced packaging, research and talent. If the first mission was about putting India on the semiconductor map, the second is about filling in the map.

THE CORE SHIFT
If the first mission was about putting India on the semiconductor map, the second is about filling in the map.

And the largest pools of wealth may emerge not in the most photographed factories, but in the less glamorous layers that make those factories productive.

India Does Not Need To Recreate Taiwan

The global semiconductor subsidy race has changed the economics of industrial policy. The United States’ CHIPS and Science Act provides USD 52.7 billion for semiconductor manufacturing, research and related programmes. Europe’s Chips Act is designed to mobilise more than EUR 43 billion of policy-driven investment.

China has spent much longer building a broad electronics and semiconductor supply chain in which state capital, domestic demand, manufacturing depth and export scale reinforce one another. India is entering this race later and with less fiscal firepower. That is precisely why copying the leaders would be a poor strategy.

NITI Aayog’s 2026 roadmap for the sector is unusually explicit on this point. India should not define success as catching Taiwan in the leading-edge foundry race. It should go deep where domestic demand, engineering talent and geopolitical position offer a plausible route to scale: mature-node logic, specialty analog and mixed-signal chips, compound semiconductors such as silicon carbide and gallium nitride, advanced packaging, design and system architecture, and critical materials.

This matters because investors often equate technological sophistication with economic attractiveness. The two are not always the same.

The world’s attention is dominated by the smallest process nodes used in artificial intelligence accelerators and high performance computing. Yet automobiles, industrial systems, power electronics, telecom equipment, appliances and Defence platforms still depend heavily on mature-node analog, power management and microcontroller products.

A 28-nanometre chip may be less glamorous than a frontier AI processor, but once qualified into a vehicle, power system or defence platform, it can sit inside a long product cycle with meaningful switching costs. That is much closer to India’s immediate opportunity.

NITI Aayog estimates that India’s semiconductor demand could rise from USD 37 billion in FY25 to USD 87 billion in FY30 and roughly USD 206 billion by FY35. Electronics production is projected to move from USD 134 billion in FY25 to USD 317 billion by FY30 and about USD 750 billion by FY35. The country already accounts for nearly one-fifth of the global semiconductor design workforce, yet 90–95 per cent of current domestic semiconductor demand is met through imports.

The mismatch is striking. India has engineers working on some of the world’s most sophisticated chips, a rapidly expanding electronics market, and growing strategic demand from automobiles, power systems, telecom, data centres and defence. Yet it captures only a small share of the manufacturing and intellectual-property value generated around that demand.

The import bill makes the vulnerability visible. Imports of semiconductor products covered by the relevant HS codes climbed from USD 5.7 billion in FY17 to USD 30.3 billion in FY25, a 23 per cent compound annual growth rate according to NITI Aayog’s compilation of Ministry of Commerce data. Cumulatively, India spent almost USD 150 billion on such imports over FY17–FY25. If that historical growth rate continued mechanically, the annual import bill could become vastly larger by 2035.

Semicon 2.0 is an attempt to change that trajectory. Its six policy pillars span design; semiconductor machines and materials; additional fabs; ATMP (Assembly, Testing, Marking and Packaging) and OSAT (Outsourced Semiconductor Assembly and Test); research and development; and talent. The ordering is revealing. Fabrication is only one part of the architecture.

The first semiconductor mission was necessarily project centric. India needed anchor investments to establish credibility. Tata Electronics’ Dholera fab, Micron’s assembly and test operations, Tata’s packaging project in Assam, CG Semi and Kaynes Semicon create industrial nodes around which suppliers, engineers and customers can begin to cluster.

But the second mission has to become economics-centric. The question is no longer how many plants are announced. It is how much of the value chain becomes locally embedded, technologically defensible and commercially viable. That shift should also change the way investors think about the theme.

The headline fab may be the most strategically important asset and still not be the best place for private capital to earn excess returns. Fabs require enormous upfront investment, continuous process upgrades, high utilisation and demanding operational discipline.

They are exposed to semiconductor cycles, customer concentration and the risk that technology moves faster than the depreciation schedule of the plant. Subsidies reduce project risk; they do not repeal industry economics. The more interesting question is what grows around the fab once the fab exists.

The Wealth Pools May Sit One Layer Below The Headline

The first 12 approved manufacturing projects provide an early clue to India’s chosen path. Nine are packaging units. The remainder comprise one silicon fab, one silicon-carbide fab and an integrated gallium-nitride Micro LED display fab. That mix says more about India’s practical strategy than a thousand speeches about becoming a semiconductor superpower.

Packaging And Testing Are The First Major Value Pool

Outsourced semiconductor assembly and test, or OSAT, gives India a more attainable entry point than frontier wafer fabrication. But the phrase can be misleading because packaging itself is moving rapidly up the technology curve. As computing systems become more complex, packaging increasingly determines power efficiency, thermal performance, latency and system-level economics. The frontier is moving from simply shrinking transistors to combining processors, memory, sensors and specialised chiplets within sophisticated packages.

NITI Aayog argues that India should aim to become a top-three global destination for OSAT and advanced packaging. That ambition is credible only if the country moves beyond basic, price-led assembly. The real economic prize is in package design, heterogeneous integration, testing expertise, specialised processes and the customer qualification that follows.

That is why CG Power and Kaynes Technology have attracted so much market attention. CG Semi entered commercial production in 2026, giving CG Power a direct operating foothold in semiconductor packaging alongside its established industrial and power businesses. Kaynes, already an electronics manufacturing company, is simultaneously building OSAT and printed-circuit-board capabilities.

For investors, however, announced capacity is the least useful metric. Yield, utilisation, package complexity, customer quality, qualification cycles and the proportion of revenue generated without exceptional policy support matter more. A plant producing huge volumes of commodity packages at weak utilisation is a very different business from a facility embedded in automotive, industrial or power-semiconductor programmes where qualification barriers are high.

The second value pool lies between semiconductors and finished electronics: printed circuit boards, camera modules, displays, interconnects, power modules and other components.

This is where investors’ enthusiasm should be concentrated because the earnings visibility is nearer. Based on this, manufacturing and PCBs are among the largest immediate investment opportunities, and companies such as Dixon Technologies, Cyient DLM and Syrma SGS are among the preferred EMS companies. The logic is straightforward. India has become very good at scaling final electronics assembly. It has not yet captured the same depth of value inside the finished product.

The first mobile manufacturing incentive programme demonstrated both the achievement and the limitation. India scaled handset production and exports dramatically, but the next stage is to move down the bill of materials into modules, components and design. That is the link between the electronics-manufacturing story and Semicon 2.0.

For companies such as Dixon, Syrma, Kaynes and Amber Enterprises, the strategic direction is compelling. Moving from contract assembly towards modules, PCBs, components, design and semiconductor-adjacent processes increases the amount of economic value captured domestically. But EMS remains a business where customer bargaining power can be formidable. Global brands can demand cost reductions, share incentive economics and reallocate volume across vendors. Revenue can grow at breathtaking rates while operating margins remain modest.

The key distinction is whether localisation merely adds throughput or creates proprietary capability, switching costs and better returns on capital.

The third and potentially most underappreciated value pool is machines, materials, chemicals and gases. This may turn out to be Semicon 2.0’s most interesting innovation from an equity market perspective because it broadens the opportunity beyond companies that already carry the ‘semiconductor’ label.

WHERE THE MARKET MAY BE EARLY
The most attractive ‘semiconductor’ investment may eventually be a company whose core product is a gas, chemical, substrate, precision component or piece of process equipment.

A functioning fab and packaging ecosystem consumes an extraordinary range of inputs: specialty gases, wet chemicals, substrates, adhesives, ceramics, quartz parts, filters, vacuum systems, precision-machined components, clean-room equipment, power conditioning, water treatment, automation and maintenance services. Many of these businesses are less visible than chip fabrication, yet they can possess demanding qualification standards and sticky customer relationships.

Previous Indian industrial cycles offer a useful analogy. The greatest wealth created by a large infrastructure build-out does not always accrue to the owner of the infrastructure. It can accrue to specialised suppliers whose products are repeatedly consumed across multiple projects and whose qualification barriers are hard to replicate.

India does not yet have a deep listed universe of pure-play semiconductor materials and equipment companies. That is precisely why this part of the market deserves attention. Over the next five years, existing industrial, precision-engineering and specialty-material businesses may enter semiconductor supply chains through qualification, joint ventures or technology partnerships. Some will fail. A few may discover that a relatively small semiconductor division creates disproportionate value because the product is difficult to qualify and expensive for the customer to replace.

The relevant question will not be whether a company ‘supplies semiconductors’. It will be what it supplies, how critical that input is, how long qualification takes, whether substitutes are readily available and whether changing vendor forces the customer to revalidate the process.

The fourth value pool is design and intellectual property, where India’s comparative advantage is most obvious and its listed market representation least satisfactory.

India has long been a major design centre for multinational semiconductor companies. Semicon 2.0 seeks to convert more of that human capital into Indian-owned products, architectures and IP. This is an important distinction. Engineering services monetise talent by the hour or project. Semiconductor IP can monetise ownership repeatedly across customers and generations of products. The economics can be exceptional when it works. The difficulty is that it requires patient capital, expensive tape-outs, customer validation and tolerance for technical failure. India will also remain deeply dependent on global tools and equipment. Electronic-design-automation software is concentrated in a small set of global vendors, while advanced lithography and much of the process equipment stack will remain imported for years.

Strategic autonomy in semiconductors does not mean autarky. Taiwan, South Korea, Japan, Europe and the United States are themselves interdependent. India’s winning model will be one that owns more critical IP, materials and manufacturing capability while remaining deeply plugged into global technology networks.

The Market Is Already Confusing Exposure With Economics

Every industrial policy creates a vocabulary before it creates cash flow.

‘Semiconductor’, ‘electronics manufacturing’, ‘localisation’, ‘OSAT’ and ‘advanced packaging’ have rapidly become valuation narratives in Indian equities. The danger is obvious. A company can be exposed to the theme without the theme becoming economically material to shareholders for years. That is where the divergence inside brokerage research becomes useful.

Motilal Oswal’s July sector work is structurally bullish. It argues that Semicon 2.0 broadens policy beyond fabs and packaging into materials, specialty gases, modules, PCBs and other upstream components. It expects a major downstream impact over the next five years and favours Dixon, Cyient DLM and Syrma SGS within EMS. That is a coherent industry view.

But single-stock research shows why industry optimism cannot be converted mechanically into stock conviction.

Kaynes Technology is the clearest example. Following its Q1 FY27 results, Motilal Oswal retained a Buy rating and a ₹5,000 target, expecting core EMS growth to remain strong and OSAT and PCB to emerge as new growth engines as commercialisation ramps from the second half of FY27. Nuvama moved to Reduce with a ₹3,450 target, pointing to margin pressure and valuation after cutting earnings estimates. Nomura retained Neutral with a ₹4,094 target and highlighted elevated working capital, weak cash conversion, large investment commitments in OSAT and PCB, subsidy dependence and execution risk.

The striking point is that all three can be broadly right about the semiconductor opportunity while disagreeing sharply about the stock.

Semiconductor expansion changes a company’s financial architecture. It raises fixed assets, depreciation and financing needs before it necessarily generates cash. New businesses can require inventories and receivables to rise before utilisation stabilises. A company that previously deserved a relatively asset-light growth multiple can become more capital intensive at exactly the moment investors are assigning it a larger thematic premium.

That makes cash conversion more important than order-book growth.

It also gives an advantage, though not immunity, to companies where semiconductor optionality is supported by an established cash-generating franchise. CG Power is an interesting case because the semiconductor venture sits beside sizeable power and industrial businesses rather than constituting the entire earnings story. The operating risk remains real, but the financing architecture is different.

Dixon presents another version of the same tension. It is one of the most important companies in India’s electronics manufacturing story and has demonstrated an ability to scale across product categories and large customers. Its backward integration into components aligns closely with the direction of government policy. But a high valuation means shareholders are not paying merely for government support. They are paying in advance for years of successful execution, market-share gains, localisation and improved economics.

The risk is not necessarily that Semicon 2.0 fails. The risk is that the policy succeeds while a particular equity disappoints because too much of that success was capitalised in the share price before the cash flows arrived.

At the smaller end of the market, investors should be even more sceptical. A semiconductor narrative can be built quickly around a memorandum of understanding, proposed plant, technology partnership or addressable-market slide. Semiconductor revenue cannot. Qualification cycles are long, manufacturing yields are unforgiving, and a customer’s willingness to move a chip or component into repeat production depends on reliability measured over time.

In this industry, the distance between an announcement and a durable Order Book can be measured in years.

That suggests a more demanding framework for analysing listed beneficiaries. First, what percentage of future revenue can genuinely come from semiconductor-linked activity? Second, what is the incremental capital required to earn that revenue? Third, what returns remain after depreciation, working capital and subsidy effects are normalised? Fourth, is the business protected by IP, process know-how or qualification barriers, or is it primarily a capacity provider? And finally, is the market already valuing optionality as though execution were certain?

The semiconductor opportunity is not uniform across listed companies. Some businesses have direct exposure through OSAT and packaging, while others participate through electronics manufacturing, PCBs, components and semiconductor-adjacent capabilities. The difference matters because revenue growth, capital intensity and valuation expectations vary significantly across these categories.

The common thread across these companies is not semiconductor revenue alone, but their ability to capture higher-value layers of the ecosystem. Investors should therefore focus less on the label attached to a company and more on whether semiconductor-related investments create durable competitive advantages, stronger returns on capital and improved bargaining power.

The Real Test Is Whether Subsidy Becomes Industrial Habit

It will be easy to judge Semicon 2.0 by counting factories, announced investments, and production milestones. Those numbers matter, but they will not tell investors where durable wealth is being created. The better test is whether the programme changes industrial behaviour.

Do Indian electronics manufacturers move from assembly into components and design? Do global semiconductor companies qualify Indian vendors for products sold outside India, rather than merely for locally incentivised output? Do OSAT plants move into more complex packages rather than compete principally on cost? Do Indian materials and precision engineering firms become recurring suppliers to several fabs? Do design start-ups build owned IP that survives beyond grants? And, most importantly, do these businesses generate acceptable returns after incentives decline?

Those questions expose the tension at the heart of semiconductor policy. Governments care about resilience, strategic autonomy, employment, technology access, and national security. Shareholders care about free cash flow and returns on incremental capital. Sometimes those objectives align beautifully. Sometimes a strategically essential industry earns mediocre private returns because too many governments subsidise too much capacity.

Semiconductors are especially vulnerable to that outcome. The industry is cyclical, capital-intensive, and geopolitically charged. The U.S., Europe, China, Japan, South Korea, and India are all spending public money to influence where capacity is built. Some segments can therefore move into overcapacity even while shortages persist elsewhere. India needs discipline as much as ambition.

The encouraging feature of Semicon 2.0 is that its architecture appears to recognise this. It does not define the mission solely around leading-edge fabs. It gives explicit weight to mature and compound semiconductors, packaging, design, equipment, materials, R&D, and talent. NITI Aayog goes further by arguing that India should become indispensable to the global ecosystem rather than imitate existing leaders. That is the right strategic instinct.

India does not need to fabricate the world’s most advanced AI processor in the next few years to create a valuable semiconductor industry. It can build defensible positions in power semiconductors, mature-node products, advanced packaging, chip design, modules, precision components, and materials, using domestic demand as an anchor while meeting global qualification standards. For investors, this suggests four filters.

The first is bargaining power. The useful question is not ‘Which stocks are semiconductor plays?’ but ‘Where will bargaining power increase as India localises the value chain?’ That directs attention towards businesses with qualification barriers, embedded customer relationships, proprietary processes, recurring consumables, and owned IP.

INVESTOR FILTER
Do not just ask which stocks are semiconductor plays. Ask where bargaining power improves as India localises the value chain.

The second is capital discipline. Semiconductor-linked growth that requires repeated equity issuance, weakens cash conversion, or depends on subsidies to produce acceptable returns deserves a different valuation from growth funded internally and supported by durable customer economics.

The third is time. Public markets are capable of discounting a decade of industrial change in a few quarters. Factories are commissioned slowly. Yields improve gradually. Customer qualifications cannot be accelerated to match investor enthusiasm. The gap between policy time and market time will create both opportunity and disappointment.

The fourth is purity of exposure, which should be viewed with more suspicion than admiration. The best investment may not be the company with the highest percentage of revenue explicitly labelled ‘semiconductor’. It may be an industrial company, materials supplier, electronics manufacturer, or design business whose existing capability lets it capture a high-return niche as the ecosystem develops.

Semicon 2.0 will almost certainly create factories. It should create jobs, technical capability, and a more resilient electronics supply chain. Whether it creates equally impressive stock market wealth will depend on where profits settle after subsidies, customers, and competition have done their work. That is why the ₹1.27 lakh crore headline is both important and incomplete.

THE INVESTMENT THESIS
The factories may be strategically essential. The more durable shareholder economics could sit one layer below them.

The first phase of India’s semiconductor ambition was about proving that plants could be built. The second will be about proving that an ecosystem can compound.

If that happens, the biggest winners may not be the companies standing at the centre of government photographs. They may be the firms supplying the package substrate, specialty chemical, precision component, qualified module, testing expertise, or Indian-owned IP that customers cannot easily replace. India does not need to recreate Taiwan to create semiconductor wealth. It needs to become difficult for the global semiconductor industry to route around. That is a far more achievable ambition. It may also be a far more valuable one.
